109
Diameter of cutting edge
Corner Radius
Cutting length
Neck Relief Length
Overall Length
Products :
| D h10 | d h6 | L | l | Z | Shank ref. |
Coatings (Balinit®) |
Code | Order | |
|---|---|---|---|---|---|---|---|---|---|
| 2,00 | 6,00 | 38 | 4,00 | 4 | HA | Alcrona | HMG109020 | ||
| 3,00 | 6,00 | 38 | 5,00 | 4 | HA | Alcrona | HMG109030 | ||
| 4,00 | 6,00 | 38 | 7,00 | 4 | HA | Alcrona | HMG109040 | ||
| 5,00 | 6,00 | 38 | 8,00 | 4 | HA | Alcrona | HMG109050 | ||
| 6,00 | 6,00 | 38 | 8,00 | 4 | HA | Alcrona | HMG109060 | ||
| 8,00 | 8,00 | 43 | 11,00 | 4 | HA | Alcrona | HMG109080 | ||
| 10,00 | 10,00 | 50 | 13,00 | 4 | HA | Alcrona | HMG109100 | ||
| 12,00 | 12,00 | 63 | 14,00 | 4 | HA | Alcrona | HMG109120 | ||
| 2,00 | 6,00 | 38 | 4,00 | 4 | HA | Futura | HMF109020 | ||
| 3,00 | 6,00 | 38 | 5,00 | 4 | HA | Futura | HMF109030 | ||
| 4,00 | 6,00 | 38 | 7,00 | 4 | HA | Futura | HMF109040 | ||
| 5,00 | 6,00 | 38 | 8,00 | 4 | HA | Futura | HMF109050 | ||
| 6,00 | 6,00 | 38 | 8,00 | 4 | HA | Futura | HMF109060 | ||
| 8,00 | 8,00 | 43 | 11,00 | 4 | HA | Futura | HMF109080 | ||
| 10,00 | 10,00 | 50 | 13,00 | 4 | HA | Futura | HMF109100 | ||
| 12,00 | 12,00 | 63 | 14,00 | 4 | HA | Futura | HMF109120 | ||
| 2,00 | 6,00 | 38 | 4,00 | 4 | HA | Uncoated | HM0109020 | ||
| 3,00 | 6,00 | 38 | 5,00 | 4 | HA | Uncoated | HM0109030 | ||
| 4,00 | 6,00 | 38 | 7,00 | 4 | HA | Uncoated | HM0109040 | ||
| 5,00 | 6,00 | 38 | 8,00 | 4 | HA | Uncoated | HM0109050 | ||
| 6,00 | 6,00 | 38 | 8,00 | 4 | HA | Uncoated | HM0109060 | ||
| 8,00 | 8,00 | 43 | 11,00 | 4 | HA | Uncoated | HM0109080 | ||
| 10,00 | 10,00 | 50 | 13,00 | 4 | HA | Uncoated | HM0109100 | ||
| 12,00 | 12,00 | 63 | 14,00 | 4 | HA | Uncoated | HM0109120 |
