353
Diameter of cutting edge
Corner Radius
Cutting length
Neck Relief Length
Overall Length
Products :
| D k12 | d | L | l | α | α | Z |
Coatings (Balinit®) |
Code | Order | |
|---|---|---|---|---|---|---|---|---|---|---|
| 1,50 | 5,00 | 40 | 2,00 | 118 | 60 | 2 | Uncoated | PCC353150 | ||
| 2,00 | 6,00 | 45 | 2,50 | 118 | 60 | 2 | Uncoated | PCC353200 | ||
| 2,50 | 8,00 | 50 | 3,10 | 118 | 60 | 2 | Uncoated | PCC353250 | ||
| 3,00 | 10,00 | 55 | 3,90 | 118 | 60 | 2 | Uncoated | PCC353300 | ||
| 4,00 | 10,00 | 55 | 5,00 | 118 | 60 | 2 | Uncoated | PCC353400 | ||
| 5,00 | 12,00 | 63 | 6,30 | 118 | 60 | 2 | Uncoated | PCC353500 | ||
| 6,00 | 18,00 | 77 | 8,00 | 118 | 60 | 2 | Uncoated | PCC353600 | ||
| 1,50 | 5,00 | 40 | 22,40 | 118 | 60 | 2 | Alcrona | NIG353150 | ||
| 2,00 | 6,00 | 45 | 2,50 | 118 | 60 | 2 | Alcrona | NIG353200 | ||
| 2,50 | 8,00 | 50 | 3,10 | 118 | 60 | 2 | Alcrona | NIG353250 | ||
| 3,00 | 10,00 | 55 | 3,90 | 118 | 60 | 2 | Alcrona | NIG353300 | ||
| 4,00 | 10,00 | 55 | 5,00 | 118 | 60 | 2 | Alcrona | NIG353400 | ||
| 5,00 | 12,00 | 63 | 6,30 | 118 | 60 | 2 | Alcrona | NIG353500 |
