10B
Diameter of cutting edge
Corner Radius
Cutting length
Neck Relief Length
Overall Length
Products :
| D js16 | α | S js16 | d 0,00000 | Z |
Coatings (Balinit®) |
Code | Order | |
|---|---|---|---|---|---|---|---|---|
| 40,00 | 45 | 10,0 | 10,0 | 14 | Uncoated | SIL10B404 | ||
| 40,00 | 50 | 13,0 | 10,0 | 14 | Uncoated | SIL10B405 | ||
| 40,00 | 60 | 13,0 | 10,0 | 14 | Uncoated | SIL10B406 | ||
| 50,00 | 45 | 13,0 | 13,0 | 16 | Uncoated | SIL10B504 | ||
| 50,00 | 50 | 16,0 | 13,0 | 16 | Uncoated | SIL10B505 | ||
| 50,00 | 60 | 16,0 | 13,0 | 16 | Uncoated | SIL10B506 | ||
| 63,00 | 45 | 18,0 | 16,0 | 16 | Uncoated | SIL10B634 | ||
| 63,00 | 50 | 20,0 | 16,0 | 16 | Uncoated | SIL10B635 | ||
| 63,00 | 60 | 20,0 | 16,0 | 16 | Uncoated | SIL10B636 | ||
| 80,00 | 45 | 22,0 | 22,0 | 18 | Uncoated | SIL10B804 | ||
| 80,00 | 50 | 25,0 | 22,0 | 18 | Uncoated | SIL10B805 | ||
| 80,00 | 60 | 25,0 | 22,0 | 18 | Uncoated | SIL10B806 | ||
| 100,00 | 45 | 28,0 | 28,0 | 20 | Uncoated | SIL10B104 | ||
| 100,00 | 50 | 32,0 | 27,0 | 20 | Uncoated | SIL10B105 | ||
| 100,00 | 60 | 32,0 | 27,0 | 20 | Uncoated | SIL10B106 |
